record TSA 20 – the allrounder

The internationally approved redundant design (RED) for escape doors consists of a double drive unit, two combined but independent controls, and a battery to perform an emergency movement in case of power failure.

Based on the record system 20, the record STA 21 has been modified to meet the requirements of light to medium-heavy door applications. Both have the same system, enabling the interactive exchange of information between control, sensors and electronic remote control unit.

Just as inviting and reliable as the traditional sliding doors, but more impressive in construction and operation are our two or four leaf telescopic sliding doors. In comparison with the traditional sliding door, they take up about 30 % less space thanks to their narrower leaves, and can cover opening widths of up to 3 000 mm. The maximum door weights range from 2 x 80 kg for single, and 4 x 50 kg for telescopic sliding doors on both sides.

Just as inviting and reliable as the traditional sliding doors, but more impressive in construction and operation are our two or four leaf telescopic sliding doors. In comparison with the traditional sliding door, they take up about 30 % less space thanks to their narrower leaves, and can cover especially large opening widths of up to 4 000 mm. The maximum door weights range from 2 x 170 kg for single, and 4 x 130 kg for telescopic sliding doors on both sides.

The reinforced DUO-drive is equipped with a second motor and matching controller. It closes the gap between the record STA 20 all-round sliding door drive, and the record STA 22 unit, which was designed for particularly heavy automatic doors. In contrast to the STA 22 model, however, the DUO drive is also available for drives with low housing covers of 108 and 150 mm in height.
