Escape door systems (CO48)
This is an entrance of originality, with extraordinary looks. The angle is freely selectable between 90° and 180° and can be applied inside or outside. With obtuse angles, this type of door is often fitted to operate over a large radius, and is also widely used in place of curved doors.
The well-proven double and single-leaf classic sliding doors from record are at the very centre of the product range, and are suitable for almost any application. The modular drive and profile systems guarantee a reliable and low-noise operation over long periods. The perfectly designed doors with their elegant appearance can be expanded according to customer requirements with regard to security, performance and convenience. Depending on the requirements, narrow, standard or robust glass profiles are used for the glass doors, and all models can be equipped with escape route safety systems.
Based on the record system 20, the record STA 21 has been modified to meet the requirements of light to medium-heavy door applications. Both have the same system, enabling the interactive exchange of information between control, sensors and electronic remote control unit.
The robust STA 22 automatic door is particularly suitable for special entrances and applications using heavy door leaves. Operator technology is particularly stable and reliable and has maintained its position successfully in the market for many years. The STA 22 automatic sliding door is the ideal solution for special heavy duty applications.
record THERMCORD is an automatic door system that has thermally separated door profiles with heat insulating properties. The ift Rosenheim determined an achievable heat transmission coefficient (UD) of 1.1 W / m² K featuring approved insulating glazing. THERMCORD is employed as an inside or outside door in areas with a – even temporarily – high temperature differential.
record THERMCORD RC 2 / RC 3 is the ideal entrance door for your retail store, hotel or office building. You will receive effective burglar resistance in combination with efficient, energy-saving properties, which reduce your heating and air-conditioning costs.
With normal sliding doors, fixed side panels block up to two thirds of the passageway. With the record TOS total opening system, however, this area remains fully accessible. The TOS is not only suitable for emergency situations, but also ideal for loading bulky items. Most common applications of the record TOS are in vehicle salesrooms, shopping centres, department stores, furniture outlets, and buildings with high volumes of pedestrian traffic.
Just as inviting and reliable as the traditional sliding doors, but more impressive in construction and operation are our two or four leaf telescopic sliding doors. In comparison with the traditional sliding door, they take up about 30 % less space thanks to their narrower leaves, and can cover especially large opening widths of up to 4 000 mm. The maximum door weights range from 2 x 130 kg for single, and 4 x 90 kg for telescopic sliding doors on both sides.
Based on the record system 20, the record STA 21 has been modified to meet the requirements of light to medium-heavy door applications. Both have the same system, enabling the interactive exchange of information between control, sensors and electronic remote control unit.
Just as inviting and reliable as the traditional sliding doors, but more impressive in construction and operation are our two or four leaf telescopic sliding doors. In comparison with the traditional sliding door, they take up about 30 % less space thanks to their narrower leaves, and can cover opening widths of up to 3 000 mm. The maximum door weights range from 2 x 80 kg for single, and 4 x 50 kg for telescopic sliding doors on both sides.
Just as inviting and reliable as the traditional sliding doors, but more impressive in construction and operation are our two or four leaf telescopic sliding doors. In comparison with the traditional sliding door, they take up about 30 % less space thanks to their narrower leaves, and can cover especially large opening widths of up to 4 000 mm. The maximum door weights range from 2 x 170 kg for single, and 4 x 130 kg for telescopic sliding doors on both sides.
